TOLLKEEPERS'
LIBRARY
Solo Project
​
Type: Architectural, Institutional
Location: Toronto, ON
Timeline: September - December 2016
​
AutoCAD, Revit, Twinmotion, Photoshop
​
The project goal is to construct a net-zero building limited to 56 sq.m (600 sq.ft) that seamlessly integrates into nature, preserving the wildlife habitat and minimizing disturbance.
The Tollkeepers' Cottage is a heritage building originally used in the late 1700s and has since been restored to its original appearance to serves as a museum that showcases its history. My proposal encompasses the addition of a library to the site, thoughtfully placed on an underutilized area to complement the existing heritage building.
1
2
3
5
6
4
5
Site Plan Elements:
1. Proposed Building
2. Existing Tollkeeper's Cottage
3. Existing Stairs and Path
4. Existing Transportation Stop
5. Proposed Stairs and Path
6. Proposed Terrace
The library was carefully designed to a size of under 56 sq.m to avoiding competition with the restored cottage, and to minimize disruption to the surrounding natural habitat.
READING AREA
18.7 m2
ENTRY
4.3 m2
BOOKS
9.8 m2
KITCHENETTE
3.6 m2
BOOKS
3.9 m2
WC
3.2 m2
COURTYARD
To achieve a carbon free building, we have integrated the Pluvia rainwater system for energy generation and reusable rainwater collection. Furthermore, solar panels have also been installed on the south-facing roof. By harvesting the power of both these renewable sources, the building is expected to generate enough energy to sustain its lighting fixtures and ventilation systems
ahhh ... look at all that rain getting collected
